Building Lab, part 2: Shapes and Building

These investigations are designed so that the students can answer the question which shape is more stable, a triangle or a square.

Building with Straws

Activities and photos from 6/23/08.

Begin by building shapes using straws and paper clips. To connect two straws, slip the wide end of a paper clip into the end of one straw. Hook a second paper clip to the first. Now insert the wide end of the second clip into a second straw.

Compare the stability of the shapes. Stand each shape up and press down on the top corner. What happens? How much does each one bend and twist? How hard can you press down on each shape before it collapses?

When compression force is applied to the joints, a triangle changes shape less than a square, because the compression in the two sides is balanced by the tension in the crosspiece at the bottom, which pulls the sides together, making it a more stable shape  When compression is applied to a square, the joints rotate easily, and the shape changes.

Other Investigations

Can you reinforce the less stable shape by adding straws and paper clips?

Build the most stable structure you can using straws and paper clips. How much weight can your structure support?

Building with Toothpicks and Gum Drops

Activities and photos from 6/23/08.

Triangles make structures more stable because they formed a truss, which is a skeleton-like structure composed of struts, some of which are in compression and some in tension, which are joined to form a series of triangles.

Activities and photos from 6/23/08.

Have your students begin by building a bridge with trusses by constructed a rectangular box of toothpicks and gumdrops. Next, test its stability by pressing down on it and wiggling it and your students should find that it is not so stable.

Activities and photos from 6/23/08.

Next challenge them to add more materials to strengthen the box, by adding cross-pieces and triangular braces. Then have them extend their trusses to see how wide a gap they can make that is still stable.

Activities and photos from 6/23/08.

Shape Walk

source
Bollman Truss Bridge, spanning Little Patuxent River near Savage Mill in Savage, MD.

Take a walk with a camera and scavenger hunt looking for examples of shapes used in structures. Scaffolding cross-braces and trusses under bridges and railroad overpasses are good places to see triangles.

Building Lab, Part I: Compression, Tension and Torsion in Building Materials

In order for students to understand how to choose the best building materials for the project they choose to build, students must understand how physical science comes into play. Forces act on building materials in many ways, and to help students learn about this, they can perform hands-on tests on basic building materials that can be found around the house, and then apply what they have learned to analyzing actual building structures. But first they must first learn some vocabulary words.

Compression (Squeezing)

Compression is a force that squeezes a material together, which tends to make the material become shorter. The lower columns of a skyscraper, for example, are compressed by the heavy weight above them.

Tension (Stretching)

Tension is a force that stretches a material apart which tends to make the material become longer. For example, the cables in a suspension bridge have the weight of the roadway and all the cars traveling on it pulling on them, creating tension on the cables.

Bending

When a straight material becomes curved, one side squeezes together and the other side stretches apart. This action is called bending. The top side of the metal bar is pulled apart in tension, and the bottom side is squeezed together in compression. This combination of opposite forces produces an action called bending.

Shear (Sliding)

Shear is a force that causes parts of a material to slide past one another in opposite directions. For example, during an earthquake, parts of a roadway can shear or slide in opposite directions.

Torsion (Twisting)

Torsion is an action that twists a material. For example, a bridge can twist violently in strong winds and collapse. The twisting force is called torsion.

Builders Need to Know Their Materials

Different materials have varying abilities to withstand compression, tension, and torsion. Students can get a chance to test materials around the house to learn about these terms and about the building materials. Send your students on a scavenger hunt to find building materials such as yarn, popsicle sticks, pipe cleaners, clay, sponges, erasers, rubber bands, paper-towel tubes, pencils, cardboard, aluminum foil, drinking straws, tiles, or cloth.

Testing the Materials

Students can perform three tests on the materials gathered to determine the tension, compression and torsion abilities of each of the samples.

Tension: To test the material in tension, pull on it or tug it from both ends.

Compression: To test the material in compression, push it together from both ends.

Torsion: To test the material in torsion, twist the two ends in different directions.

Demonstrate how to test the materials by choosing one and tug, push and twist on the sample to test tension, compression and torsion. For example, using a rope to demonstrate the tests, have two kids tug on the ends of a rope (tension), then push the ends together (compression), and finally twist the ends of the rope (torsion). They should find that the rope is strong in tension but weak in compression and torsion.

Now have each student pick a few items from what they have gathered and predict which ones will be strongest in tension, which in compression and which in torsion.

Now, have them test the materials by performing the same tests which you had demonstrated on them. Students will have to help each other in pairs to accomplish this. Then they should record their findings, ranking the materials from 1-4 (1 Very weak! It crumples or breaks with hardly any force. 2 Only fair—it can't withstand much force. 3 Pretty good—it takes a lot of force to break it. 4 Super strong! We can't break it.) They should find that the materials that are strongest in tension:  are the string, yarn, pipe cleaner, popsicle stick, ceramic tile, cardboard, drinking straw, cloth, rubber band (strong but very flexible), rubber eraser, paper-towel tubes and the pencil. The materials that are strongest in compression are the popsicle stick, clay (limited), ceramic tile, rubber eraser, paper-towel tubes (limited) and the pencil. The materials that are strongest in torsion are the ceramic tile, rubber eraser (limited), paper-towel tubes and the pencil.

Discussion

Which materials were strongest in resisting each type of force? Did any of these results surprise you? Why or why not?

Which materials were strongest across all three tests? How would you describe those materials?

Discuss how some materials are flexible under a type of stress–they change shape as opposed to breaking outright. When might flexibility be desirable? When is stiffness required? (Parts of structures such as the cables of suspension bridges that are built to withstand shaking caused by wind gusts often have some "give." Other parts of structures, such as floor beams that support great weights, need to be rigid.)
